Description - 560W
560W Bifacial Solar Panel
Key Features
- Higher Energy Yield: The bifacial monocrystalline PERC solar panel captures sunlight on both sides, generating up to 30% more energy than traditional solar panels.
- Extreme Weather Resilience: Built for rugged climates, withstanding heat, cold, heavy snow loads, and high wind speeds, ensuring durability and consistent performance.
- Compact & High Efficiency: The high energy conversion efficiency allows for less installation space, making it an excellent option for residential and commercial solar power systems.
- Versatile Installation: Can be mounted at any angle, eliminating the need for tilt angle adjustments or additional structural analysis.
- Long-Term Reliability & Incentives: Comes with a 25-year performance warranty and qualifies for the 30% Residential Clean Energy Credit, making it a cost-effective energy solution.
Cutting-Edge Bifacial Solar Panel Design
Sungoldpower bifacial solar panels generate additional power by capturing reflected sunlight. This makes them ideal for ground-mounted solar arrays, carports, canopies, and high-exposure installations, ensuring maximum solar energy absorption.
Optimized Performance in Shaded Environments
- PERC Technology: Enhances efficiency by capturing more sunlight and converting it into usable energy.
- Half-Cut Cells & 11-Busbar Structure: Improves power generation by minimizing energy loss and reducing electrical resistance.
- Bypass Diodes: Prevents power drop-offs in partially shaded conditions, ensuring continuous energy production.
These high-efficiency bifacial solar panels provide maximum energy generation, durability, and flexibility, making them ideal for various solar power applications






Specifications
Model Type |
460W-Bifacial |
560W-Bifacial |
Peak Power (Pmax) |
460W |
560W |
Production tolerance |
±3% |
±3% |
Maximum Power Current (Imp) |
13.3A |
13.3A |
Maximum Power Voltage (Vmp) |
34.5V |
42.1V |
Short Circuit Current (Isc) |
14.13A |
14.09A |
Open Circuit Voltage (Voc) |
41.75V |
50.09V |
Maximum System Voltage |
1500V |
1500V |
Wind Resistance |
2400Pa |
2400Pa |
Output Cables |
12 AWG (1ft per cable) |
12 AWG (1ft per cable) |
Number of Cells |
120(6x 20),60 cells in series |
144(6x 24),60 cells in series |
Cell Type |
PERC Monocrystalline (7.2x 3.6 in) |
PERC Monocrystalline (7.2x 3.6 in) |
Certifications |
CE TUV |
CE TUV |
Product Weight |
60.5lbs |
67.9lbs |
Product Dimension |
75.2*44.7*1.4inch |
89.8*44.7*1.4inch |
Package Weight |
130lbs(2PCS) |
128.7lbs(2PCS) |
Package Dimension |
78.5*47.2*3.1inch(2PCS) |
92.5*47.6*3.1inch(2PCS) |
Performance |
5 year 95% output warranty 10 year 90% output warranty 25 year80% output warranty |
5 year 95% output warranty 10 year 90% output warranty 25 year80% output warranty |
Material and workmanship warranty |
10 year material and workmanship warranty.UL 61730 |
10 year material and workmanship warranty |
Downloads
460W Bifacial PERC Solar Panel User Manual
560W Bifacial PERC Solar Panel User Manual
